The Amada HG 2204 ATC enhances all of the standard features of the HG 1003 ATC by offering a longer bed length of 13-ft., 240 US ton pressure, and 112.8-ft ATC tool capacity. Quick tool setups achieved by the ATC gives users the ability to seamlessly introduce rush jobs and triple or quadruple the amount of setups performed each day.
The HG 2204 ATC is equipped with a factory-installed sheet follower to assist an operator while bending large and/or heavy parts. Parts that normally require multiple operators can now be efficiently handled by a single person, thereby reducing labor costs and reducing the hazards associated with bending these types of parts. When not in use, the sheet follower arms can be slid to the right side of the press brake for full machine accessibility.
Additional HG 2204 ATC features and benefits include:
- Ideal solution for variable lot sizes and complex tool layouts
- Increase the number of tool setups performed each day
- Reduce operator experience requirements
- ATC stores 112.8′ (26.4m) of tooling
- New AMNC 3i control
- 8-Axis Backguage with L-Shift
- Integrated bend sensor
- Factory-installed sheet follower to assist operator
- Low energy consumption
Specifications |
HG 1003 ATC |
HG 2204 ATC |
| Tonnage (US) | 110 | 240 |
| CNC Control | AMNC 3i | |
| Max. Bend Length | 118.1″ | 161.4″ |
| Max. Stroke Length | 9.8″ | |
| >Open Height | 23.4″ | |
| Distance Between Housings | 106.3″ | 148″ |
| Crowning System | (2) Hydraulic crowning cylinders | (3) Hydraulic crowning cylinders |
| Ram Repeatability | ±0.00004″ | |
| Approach Speed | 8.7″/sec. | |
| Bending Speed | 0.78″/sec. (max.) programmable | |
| Return Speed | 9.8″/sec. | |
| Backgauge | (8) axes including L-Shift | |
| Sheet Followers | N/A | Standard |
| Overall Machine Dimensions | (L) 238.1″ x (W) 126.6″ x (H) 117.3″ | (L) 280.5″ x (W) 134.4″ x (H) 130.7″ |
| Hydraulic Oil Capacity | 12.7 gal. | 32.4 gal. |
| Total Weight | 26,840 lbs. | 51,900 lbs. |
| Supply Power | 200V, 22kVA | 200V, 41kVA |
| Foot Pedal | (2) auto slide and remote | |
| Bend Angle Control | Auto Bi-S (Single) | Auto Bi-S (Dual) |
| Safety | Safety device, safety gate (tool change), light guard (slide pedal), PILZ PSENvip P (operation) | |
ATC Specs |
1003 |
2204 |
| Tool Style | AMTS ATC | |
| Punch Stockers | 15 | 18 |
| Die Stockers | 18 | 25 |
| ATC Location | Right hand | |
| Max. Tool Layout Length | 120.47″ | 157.5″ |
| Minimum Tool Pitch | 0.196″ | |
| “V” Range | 0.157″ – 1.57″ | |
| Punch Reversal Unit | Yes | |
| Punch Height | 6.7″ standard • 8.7″ special | |
